Strands Lighting Division

Siberia NR 9″ vit

Art Nr: 809208
Rek. pris: 2,499 kr (Exkl. moms)
Köp i butik
Manual
    • Unit PCS
    • Type of Lamp LED
    • PCS LED´s 34
    • Voltage (V DC) 9-32V DC
    • Theoretical effect (w) 12V 170
    • Theoretical effect (w) 24V 170
    • Theoretical lumen 20400
    • Actual lumen 11722
    • 1 LUX @ m 370
    • Kelvin 5400
    • IP-class 69K
    • Colour housing White
    • Colour lens Clear
    • Colour LED´s Amber & White
    • Beam pattern Driving beam
    • Position light Yes
    • Connection DT-4
    • Cable length (mm) 500
    • Material bracket Stainless steel
    • Material housing/chassi Aluminium
    • Material lens Polycarbonate
    • Length (mm) 228,6
    • Depth (mm) 86,7
    • Height (mm) 228,6
    • Height including bracket (mm) 249,3
    • Diameter (mm) 228,6
    • Operating temperature -20°C - +45°C
    • E-approved Yes
    • According to regulation ECE R112, R7
    • Reference number 30
    • EMC ECE R10
    • Black cable - (Negative)
    • Red cable + Positive
    • White cable White position light
    • Yellow cable Yellow Position light
    • Mounting details included Screws, washers, bolts
    • Height inner box (mm) 287
    • Weight (kg) 4
    • Length master carton (mm) 682
    • Height master carton (mm) 595
    • Width master carton (mm) 185
    • Weight master carton (kg) 17,58
    • Country of origin China
    • EAN 7350133816522
    • Warranty 3 Years
