Strands Lighting Division
Siberia NR 9″ vit
Art Nr: 809208
Rek. pris:
2,499 kr
(Exkl. moms)
- Unit PCS
- Type of Lamp LED
- PCS LED´s 34
- Voltage (V DC) 9-32V DC
- Theoretical effect (w) 12V 170
- Theoretical effect (w) 24V 170
- Theoretical lumen 20400
- Actual lumen 11722
- 1 LUX @ m 370
- Kelvin 5400
- IP-class 69K
- Colour housing White
- Colour lens Clear
- Colour LED´s Amber & White
- Beam pattern Driving beam
- Position light Yes
- Connection DT-4
- Cable length (mm) 500
- Material bracket Stainless steel
- Material housing/chassi Aluminium
- Material lens Polycarbonate
- Length (mm) 228,6
- Depth (mm) 86,7
- Height (mm) 228,6
- Height including bracket (mm) 249,3
- Diameter (mm) 228,6
- Operating temperature -20°C - +45°C
- E-approved Yes
- According to regulation ECE R112, R7
- Reference number 30
- EMC ECE R10
- Black cable - (Negative)
- Red cable + Positive
- White cable White position light
- Yellow cable Yellow Position light
- Mounting details included Screws, washers, bolts
- Height inner box (mm) 287
- Weight (kg) 4
- Length master carton (mm) 682
- Height master carton (mm) 595
- Width master carton (mm) 185
- Weight master carton (kg) 17,58
- Country of origin China
- EAN 7350133816522
- Warranty 3 Years
