Strands Lighting Division

FREEDOM BAKLJUS 4 FUNK HÖGER TRAILER

Art Nr: 900012
Rek. pris: 2,515 kr (Exkl. moms)

Välj variant

FREEDOM BAKLJUS 4 FUNK HÖGER TRAILER

Rek. pris: 2,515 kr (Exkl. moms)
Art Nr: 900012
Vald

Freedom bakljus 4funk vänster för trailer

Rek. pris: 2,515 kr (Exkl. moms)
Art Nr: 900011
Välj

FREEDOM BAKLJUS 4 FUNK VÄNSTER TRUCK

Rek. pris: 2,515 kr (Exkl. moms)
Art Nr: 900013
Välj

FREEDOM BAKLJUS 4 FUNK HÖGER TRUCK

Rek. pris: 2,515 kr (Exkl. moms)
Art Nr: 900014
Välj
Köp i butik Köp i USA
Manual Produktblad
    • Unit PCS
    • Voltage (V DC) 12-24V DC
    • Consumption (W) Rear position light: 12/24V max. 5,5W , Stop light: 12V/24V max. 5W, Rear direction indicator light: , 12V/24V max. 21W Reversing light: 12/24V max. 6W
    • Functions Rear position light, Stop light, Rear direction indicator light, Reversing light, Reflective device
    • Position light Yes
    • Connection open ends leads
    • Cable length (mm) 2000
    • Color housing Black
    • Color lens Clear tinted
    • Color LED´s White, Red and Amber
    • Material housing/chassi PP
    • Material lens PMMA
    • Length (mm) 302
    • Depth (mm) 58,3
    • Height (mm) 131
    • CC (mm) 150
    • IP-class IP6K9K
    • Operating temperature -40 - +40°C
    • E-approved Yes
    • According to regulation ECE R148, R150
    • EMC ECE R10
    • Black cable Rear position light
    • Red cable Stop light (+)
    • White cable - Negative
    • Blue cable Reversing light
    • Yellow cable Rear direction indicator light
    • Mounting details included washers, nuts
    • Length inner box (mm) 410
    • Depth inner box (mm) 100
    • Height inner box (mm) 152
    • Weight (kg) 1,325
    • Length master carton (mm) 410
    • Width master carton (mm) 340
    • Weight master carton (kg) 11,2
    • PCS in master carton 8
    • Warranty 3 Years
